MayaFlux::Buffers::SoundFileBridge Class Reference
An audio buffer that reads from a file container and writes to a dynamic stream. More...
#include <SoundFileBridge.hpp>
Inheritance diagram for MayaFlux::Buffers::SoundFileBridge:
Collaboration diagram for MayaFlux::Buffers::SoundFileBridge:
Public Member Functions | |
| SoundFileBridge (uint32_t channel_id, const std::shared_ptr< Kakshya::SoundFileContainer > &file_container, uint32_t source_channel=0) | |
| Construct a file-to-stream bridge. | |
| std::shared_ptr< Kakshya::DynamicSoundStream > | get_capture_stream () const |
| Get the output stream accumulating processed audio. | |
| void | setup_processors (Buffers::ProcessingToken token) override |
| Setup the processing chain with automatic input/output. | |
| std::shared_ptr< SoundStreamWriter > | get_stream_writer () const |
| Get the stream writer processor. | |
| Public Member Functions inherited from MayaFlux::Buffers::SoundContainerBuffer | |
| SoundContainerBuffer (uint32_t channel_id, uint32_t num_samples, const std::shared_ptr< Kakshya::StreamContainer > &container, uint32_t source_channel=0) | |
| Construct a SoundContainerBuffer for a specific channel and container. | |
| void | initialize () |
| Initialize the buffer after construction. | |
| std::shared_ptr< Kakshya::StreamContainer > | get_container () const |
| Get the backing StreamContainer. | |
| uint32_t | get_source_channel () const |
| Get the source channel in the container. | |
| void | set_container (const std::shared_ptr< Kakshya::StreamContainer > &container) |
| Update the container reference. | |
| bool | is_zero_copy () const |
| Check if buffer data is directly mapped to container (zero-copy). | |
| Public Member Functions inherited from MayaFlux::Buffers::AudioBuffer | |
| AudioBuffer () | |
| Creates a new uninitialized audio buffer. | |
| AudioBuffer (uint32_t channel_id, uint32_t num_samples=512) | |
| Creates a new audio buffer with specified channel and capacity. | |
| virtual | ~AudioBuffer () override=default |
| Virtual destructor for proper resource management. | |
| virtual void | setup (uint32_t channel, uint32_t num_samples) |
| Initializes the audio buffer with specified channel and capacity. | |
| virtual void | resize (uint32_t num_samples) |
| Adjusts the audio buffer's sample capacity. | |
| virtual void | clear () override |
| Resets all audio samples in the buffer to silence. | |
| virtual uint32_t | get_num_samples () const |
| Gets the current capacity of the audio buffer. | |
| virtual std::vector< double > & | get_data () |
| Gets mutable access to the buffer's underlying audio data. | |
| virtual const std::vector< double > & | get_data () const |
| Gets read-only access to the buffer's underlying audio data. | |
| virtual void | process_default () override |
| Applies the default audio transformation to the buffer's data. | |
| virtual uint32_t | get_channel_id () const |
| Gets the audio channel identifier for this buffer. | |
| void | set_channel_id (uint32_t id) |
| Sets the audio channel identifier for this buffer. | |
| virtual void | set_num_samples (uint32_t num_samples) |
| Sets the capacity of the audio buffer. | |
| virtual void | set_default_processor (const std::shared_ptr< BufferProcessor > &processor) override |
| Sets the default audio transformation processor for this buffer. | |
| virtual std::shared_ptr< BufferProcessor > | get_default_processor () const override |
| Gets the current default audio transformation processor. | |
| virtual std::shared_ptr< BufferProcessingChain > | get_processing_chain () override |
| Gets the audio transformation chain attached to this buffer. | |
| virtual void | set_processing_chain (const std::shared_ptr< BufferProcessingChain > &chain, bool force=false) override |
| Sets the audio transformation chain for this buffer. | |
| virtual double & | get_sample (uint32_t index) |
| Gets a reference to a specific audio sample in the buffer. | |
| virtual bool | has_data_for_cycle () const override |
| Checks if the audio buffer has data for the current processing cycle. | |
| virtual bool | needs_removal () const override |
| Checks if the buffer should be removed from the processing chain This is relevant when using SignalSourceContainers. | |
| virtual void | mark_for_processing (bool has_data) override |
| Marks the audio buffer for processing in the current cycle. | |
| virtual void | mark_for_removal () override |
| Marks the audio buffer for removal from processing chains. | |
| virtual void | enforce_default_processing (bool should_process) override |
| Controls whether the audio buffer should use default processing. | |
| virtual bool | needs_default_processing () override |
| Checks if the audio buffer should undergo default processing. | |
| bool | try_acquire_processing () override |
| Attempts to acquire processing rights for the buffer. | |
| void | release_processing () override |
| Releases processing rights for the buffer. | |
| bool | is_processing () const override |
| Checks if the buffer is currently being processed. | |
| virtual std::shared_ptr< AudioBuffer > | clone_to (uint32_t channel) |
| Creates a clone of this audio buffer for a specific channel. | |
| std::shared_ptr< Buffer > | clone_to (uint8_t dest_desc) override |
| Creates a clone of this buffer for a specific channel or usage enum. | |
| virtual bool | read_once (const std::shared_ptr< AudioBuffer > &buffer, bool force=false) |
| Reads audio data into the buffer from the audio backend. | |
| void | force_internal_usage (bool internal) override |
| Marks the buffer as internal-only, preventing root aggregation. | |
| bool | is_internal_only () const override |
| Checks if the buffer is marked as internal-only. | |
| Public Member Functions inherited from MayaFlux::Buffers::Buffer | |
| virtual | ~Buffer ()=default |
| Virtual destructor for proper resource management. | |
Private Attributes | |
| std::shared_ptr< Kakshya::DynamicSoundStream > | m_capture_stream |
| std::shared_ptr< SoundStreamWriter > | m_stream_writer |
Additional Inherited Members | |
| Protected Member Functions inherited from MayaFlux::Buffers::SoundContainerBuffer | |
| std::shared_ptr< BufferProcessor > | create_default_processor () override |
| Create the default processor (SoundStreamReader) for this buffer. | |
| Protected Attributes inherited from MayaFlux::Buffers::AudioBuffer | |
| uint32_t | m_channel_id |
| Audio channel identifier for this buffer. | |
| uint32_t | m_num_samples |
| Capacity of the buffer in audio samples. | |
| std::vector< double > | m_data |
| Vector storing the actual double-precision audio sample data. | |
| std::shared_ptr< BufferProcessor > | m_default_processor |
| Default audio transformation processor for this buffer. | |
| std::shared_ptr< BufferProcessingChain > | m_processing_chain |
| Audio transformation processing chain for this buffer. | |
| bool | m_has_data |
| Whether the audio buffer has data to process this cycle. | |
| bool | m_should_remove |
| Whether the audio buffer should be removed from processing chains. | |
| bool | m_process_default |
| Whether the audio buffer should be processed using its default processor. | |
Detailed Description
An audio buffer that reads from a file container and writes to a dynamic stream.
SoundFileBridge is a SoundContainerBuffer with built-in output streaming. It automatically sets up:
- Default processor: Reads from file container (inherited)
- Main chain: User processors (e.g., filters, effects)
- Postprocessor: Writes transformed audio to output stream
Usage: auto file_buf = std::make_shared<SoundFileBridge>(0, file_container); file_buf->setup_chain();
// Optionally add processing auto filter = std::make_shared<FilterProcessor>(...); file_buf->get_processing_chain()->add_processor(filter, file_buf);
// Process for N cycles for (int i = 0; i < 100; ++i) { file_buf->get_processing_chain()->process_complete(file_buf); }
// Get the accumulated result auto result = file_buf->get_capture_stream();
Definition at line 40 of file SoundFileBridge.hpp.
The documentation for this class was generated from the following files:
