Adapter for bridging N-dimensional containers and AudioBuffer interface. More...

#include <ContainerBuffer.hpp>

Inheritance diagram for MayaFlux::Buffers::ContainerToBufferAdapter:

Collaboration diagram for MayaFlux::Buffers::ContainerToBufferAdapter:

Public Member Functions
	ContainerToBufferAdapter (std::shared_ptr< Kakshya::StreamContainer > container)

void	processing_function (std::shared_ptr< Buffer > buffer) override
	Extracts and processes data from the container into the target AudioBuffer.

void	on_attach (std::shared_ptr< Buffer > buffer) override
	Attach the adapter to an AudioBuffer.

void	on_detach (std::shared_ptr< Buffer > buffer) override
	Detach the adapter from its AudioBuffer.

void	set_source_channel (uint32_t channel_index)
	Set which channel dimension to extract from the container.

uint32_t	get_source_channel () const

void	set_container (std::shared_ptr< Kakshya::StreamContainer > container)
	Set the container to adapt.

std::shared_ptr< Kakshya::StreamContainer >	get_container () const

void	set_auto_advance (bool enable)
	Enable or disable automatic advancement of the container's read position.

bool	get_auto_advance () const

void	set_update_flags (bool update)
	Enable or disable buffer state flag updates.

bool	get_update_flags () const

Public Member Functions inherited from MayaFlux::Buffers::BufferProcessor
virtual	~BufferProcessor ()=default
	Virtual destructor for proper cleanup of derived classes.

void	process (std::shared_ptr< Buffer > buffer)
	Applies a computational transformation to the data in the provided buffer.

virtual void	set_processing_token (ProcessingToken token)
	Gets the preferred processing backend for this processor.

virtual ProcessingToken	get_processing_token () const
	Gets the current processing token for this buffer.

virtual bool	is_compatible_with (std::shared_ptr< Buffer >) const
	Checks if this processor can handle the specified buffer type.

Private Member Functions
void	analyze_container_dimensions ()
	Analyze the container's dimensions and update mapping info.

void	extract_channel_data (std::span< double > output)
	Extract channel data from the container into the output buffer.

void	on_container_state_change (std::shared_ptr< Kakshya::SignalSourceContainer > container, Kakshya::ProcessingState state)
	Respond to container state changes (e.g., READY, PROCESSED, NEEDS_REMOVAL).

Private Attributes
std::shared_ptr< Kakshya::StreamContainer >	m_container

uint32_t	m_source_channel {}

bool	m_auto_advance = true

bool	m_update_flags = true

uint32_t	m_time_reader_id = UINT32_MAX

uint32_t	m_channel_reader_id = UINT32_MAX

uint32_t	m_num_channels { 1 }

uint32_t	m_reader_id {}

uint64_t	m_consumption_offset {}

std::vector< double >	m_temp_buffer

Additional Inherited Members
Protected Attributes inherited from MayaFlux::Buffers::BufferProcessor
ProcessingToken	m_processing_token { ProcessingToken::AUDIO_BACKEND }

Detailed Description

Adapter for bridging N-dimensional containers and AudioBuffer interface.

ContainerToBufferAdapter enables seamless integration between N-dimensional data containers (such as Kakshya::StreamContainer or SoundFileContainer) and the AudioBuffer processing system. It extracts audio data from containers and presents it as a standard AudioBuffer for use in block-based DSP, node networks, and hardware output.

Key responsibilities:

Maps N-dimensional container data (time/channel/other axes) to linear audio buffer format.
Handles dimension selection, channel extraction, and position tracking.
Synchronizes processing state and lifecycle between container and buffer.
Supports automatic or manual advancement of read position for streaming or block-based workflows.
Enables zero-copy operation when possible, falling back to cached extraction as needed.

This adapter is foundational for digital-first workflows where data may originate from files, streams, or procedural sources, and must be routed into the buffer system for further processing or output. While currently focused on audio, the design can be extended to support other data container types as more reader processors are implemented.

See also: ContainerBuffer, StreamContainer, SoundFileContainer, ContiguousAccessProcessor

Definition at line 32 of file ContainerBuffer.hpp.
