MayaFlux::Core::VKFramebuffer Class Reference

Wrapper for Vulkan framebuffer. More...

#include <VKFramebuffer.hpp>

Collaboration diagram for MayaFlux::Core::VKFramebuffer:

Public Member Functions
void	cleanup (vk::Device device)
	Cleanup framebuffer.
bool	create (vk::Device device, vk::RenderPass render_pass, const std::vector< vk::ImageView > &attachments, uint32_t width, uint32_t height, uint32_t layers=1)
	Create framebuffer.
vk::Framebuffer	get () const
	Get the framebuffer handle.
uint32_t	get_height () const
uint32_t	get_layers () const
uint32_t	get_width () const
	Get framebuffer dimensions.
bool	is_valid () const
	Check if framebuffer is valid.
VKFramebuffer &	operator= (const VKFramebuffer &)=delete
VKFramebuffer &	operator= (VKFramebuffer &&) noexcept=default
	VKFramebuffer ()=default
	VKFramebuffer (const VKFramebuffer &)=delete
	VKFramebuffer (VKFramebuffer &&) noexcept=default
	~VKFramebuffer ()=default

Private Attributes
vk::Framebuffer	m_framebuffer
uint32_t	m_height = 0
uint32_t	m_layers = 1
uint32_t	m_width = 0

Detailed Description

Wrapper for Vulkan framebuffer.

Framebuffer connects render pass attachments to actual image views. Typically one framebuffer per swapchain image for presentation.

Definition at line 13 of file VKFramebuffer.hpp.

---

The documentation for this class was generated from the following files:

• VKFramebuffer.hpp
• VKFramebuffer.cpp
